Aluminium Plate & Sheet

Marine Aluminium Plate & Sheet obtains DNV, LR, BV classes and more

AAM supplies 5083, 5383, 5059 marine grade aluminium plate from 3 to 200 mm. We stock alloy 5083H116, 5083H111, 5083H321 in most customary sizes, and we can respond quickly to different, specific wishes. We also keep normal primary Aluminium ingot with the quantity of 200mt per month to ensure the fastest shipment(within 15 days).

The Aluminium plates/sheets available with us are sourced from giant manufacturers all around China mainland ( which are certified to the latest ISO standard and approved by CCS,DNV,BV,LR,NK,KR,RINA ) with Mark Stencil on individual plate/sheet showing Mill name, Alloy ,Temper,Lot No. and grade etc. We provide mill test certificates with matching heat numbers as per ASTM/EN standards with all our deliveries to give our clients traceability and confidence in the materials they source from us.

Aluminium Plate & Sheet

Aluminium Plate & Sheet |Specification

Alloy       5083/5383/5059
Temper       O/H116/H321/H112
Thickness       200mm        max
Width       2700mm      max
Length       24000mm    max
Class       DNV/ABS/LR/NK/BV/RINA/CCS/KR

Aluminium Plate & Sheet | Mechanical Property

ASTM B928Tensile Strength (Rm/mpa)Yield Strength   (Rm/mpa)Elongation            (%)
Standard Value≥305≥215≥10
Measured Value333-357.5227-25213-23
Intergranalar   Corrosion (mg/cm2)Exfoliation   CorrosionBending  Radius
≤15N,PA,PB
2-10N,PA0.5T max

Aluminium 5083 Marine Plate | Stocked Sizes

Temper/ConditionThickness (mm)Width (mm)Length (mm)
H116/H3214,5,6,8,10,12,20,25,3020006000
H1114,5,6,8,1020006000, 8000
